1991 Dodge Spirit RT 2.2L Turbo III Electronic Fuel Injection (MPI) Powertrain Diagnostic Procedures
Click to enlarge image(s)

Used factory manual in good condition.

This diagnostic procedures manual covers 1991 vehicles equipped with the 2.2L Turbo III engine with multi-point injection.

Contents:

  • DRBII Functional Flow Diagram
  • Helpful Information
  • How to use this manual
  • Visual Inspection
  • On-Board Diagnostic System
  • System Fault Messages
  • DRBII Diagnostic Read Out Box
  • DRBII Test Functions
  • Diagnostic Test Procedures
  • Required tools and Equipment
  • System Schematic
  • Operation of the DRBII for diagnostic Testing
  • Component and Connector Locations
  • Inspection of Electrical Connectors
  • Inspection of Electrical Connectors
  • Inspection of Hoses and Vacuum Lines
  • Safety Instructions
  • Definition of Normal Operating Temperature
  • Diagnostic Test Procedures
Specifications
Publisher: Chrysler Corporation
Softcover: 294 pages
Dimensions: 11.0 x 8.5 x 1.0 inches
