Over the last 50 years, literally millions of GM cars and trucks have been built with Turbo 400 automatic transmissions. While these transmissions are respected for their durability and versatility, there always comes a point where the old transmission shows signs of wear. At some point, even the best transmissions need to be rebuilt.

Respected automotive technical author Cliff Ruggles takes readers through the complex rebuild procedure of GMs most popular rear-wheel drive automatic transmission in this great new book. Enthusiasts have embraced the reliable GM Turbo Hydra-Matic 400 three-speed automatics for years, and the popularity of these transmissions is not slowing down. With his proven style, Ruggles walks through the step-by-step rebuild and performance upgrade procedures in a series of full-color photos for each of these models. Time saving tips are part of every buildup.

This is a welcome addition to your automotive library. Amateurs and professionals alike will appreciate the advice and guidance offered on every page. Even if you end up deciding to have a professional take care of your transmission repair and performance needs, this information is crucial to understanding how the power gets from the engine to the road.

Chapter 1: Tools and Equipment
 Safety Equipment
 Sockets and Wrenches
 Snap Ring Pliers
 Screwdrivers
 Measuring Devices
 Spring Compressors
 Case Holding Fixtures
 Work Surface
 Pans for Small Parts
 Cleaning Cases
 Bushing Removers and Installers
 Heli-Coils and Bolt Extractors
 Air Tools
 Punches, Chisels and Files
 Lip Seal Installation Tools
 Friction Alignment Tool
 Oil Pump Band
 Alignment Studs
 Slide Hammer
 Special Tools

 Chapter 2: Transmission Fundamentals
 Torque Converters
 Transmission Oil Pump
 Clutch Packs
 Bands and Servos
 Accumulators
 Planetary Gears
 Sprags and Roller Clutches
 Valve Body
 Chapter 3: Transmission Removal
 Chapter 4: TH400 Disassembly
 Remove External Components
 Remove Valve Body and Governor Filter
 Remove Downshift Solenoid and Separator Plate
 Remove Front Band and Low Band Apply Servos
 Remove Oil Pump, Manual Shaft and Speedometer Gear Housing
 Remove Forward Drum Clutch, Direct Drum and Band
 Remove Clutch Pack, Output Shaft and Low Band
 Final Disassembly

 Chapter 5: TH400 Assembly
 Install New Case Bushing, Solenoid Connector and Parking Pawl
 Disassemble Output Shaft and Lower Planetary Assembly
 Reinstall Planetary Assembly
 Install Low Band and Output Assembly
 Rebuild Center Support
 Reinstall Center Support
 Rebuild and Install Clutch Pack and Intermediate Band
 Rebuild Direct Clutch Pack and Install Direct Drum
 Rebuild Forward Drum
 Rebuild and Install Oil Pump Assembly
 Check Clutch Packs and Install Accumulator Piston
 Install Filter and Valve Body
 Install Exterior Components
 Chapter 6: TH400 Transbrake
 Installation Procedure

 Chapter 7: Transmission Installation

 Troubleshooting Guide
