CLYMER REPAIR MANUAL
Every Clymer contains hundreds of original photographs and illustrations developed from a complete disassembly and assembly of the ATV. This, in addition to extensive research, allows Clymer to achieve an un-matched level of detail, accuracy & clarity.

The step-by-step instructions and two column text with large print are user friendly, bold figure numbers make it easy to quickly match instructions with illustrations and photos. Thumb tabbed chapters, numbered table of contents and extensive index make it possible to locate the desired section quickly.

Models Covered:

2001-2008 HONDA TRX250EX Sportrax
2009-2012 HONDA TRX250X

Contents:

CHAPTER ONE / GENERAL INFORMATION

CHAPTER TWO / TROUBLESHOOTING

CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP

Pre-ride check list / Maintenance schedule / Tires and wheels / Battery / Engine oil and filter / Final drive gearcase oil / Control cable lubrication / General lubrication / Air and fuel system / Brake system / Spark arrestor / Suspension / Fasteners / Valve clearance / Engine compression / Spark plug / Ignition timing / Idle speed adjustment / Specifications

CHAPTER FOUR / ENGINE TOP END
Cylinder head cover / Rocker arms, pushrods and cylinder head / Valves and components / Cylinder / Piston and rings / Camshaft / Specifications

CHAPTER FIVE / ENGINE LOWER END
Removal installation / Oil cooler / Alternator cover / Flywheel and starter gears / Gearshift linkage / Oil pump / Oil screen and strainer / Crankcase and crankshaft / Engine break-in / Specifications

CHAPTER SIX / CLUTCH AND PRIMARY DRIVE GEAR
Clutch cover / clutch release mechanism / Centrifugal clutch and primary drive gear / Specifications

CHAPTER SEVEN / TRANSMISSION AND INTERNAL SHIFT MECHANISM
Transmission overhaul / Reverse idle gear assembly / Transmission inspection / Internal shift mechanism / Reverse selector cable / Specifications

CHAPTER EIGHT / FUEL, AIR AND EXHAUST SYSTEMS
Carburetor / Carburetor adjustments / Throttle housing / Throttle cable / Choke cable / Fuel tank / Fuel valve / Air box / Exhaust system / Specifications

CHAPTER NINE / ELECTRICAL SYSTEM
Battery negative terminal / Charging system / Alternator / Ignition system / Starter / Starter relay / Diode / Lighting switch / Switches / Fuse / Specifications

CHAPTER TEN / WHEELS, HUBS AND TIRES
Front wheel / Front hub / Rear wheel / Rear hub / Tires / Specifications

CHAPTER ELEVEN / FRONT SUSPENSION AND STEERING
Handlebar / Steering shaft / Tie rods / Steering knuckle / Control arms / Ball joint replacement / Shock absorbers / Specifications

CHAPTER TWELVE / REAR AXLE, SUSPENSION AND FINAL DRIVE
Shock absorber / Rear axle / Final drive / Driveshaft / Swing arm / Specifications

CHAPTER THIRTEEN / BRAKES
Brake service / Front brake pads / Front brake caliper / Front master cylinder / Brake hose replacement / Brake fluid draining / Brake bleeding / Rear brake drum / Rear brake pedal and cable / Rear brake lever / parking brake cable / Specifications

CHAPTER FOURTEEN / BODY
Retaining clips / Retaining tabs / Seat / Side covers / Fuel tank cover / Front fender / Front and rear guards / Rear fender / Footpegs and mud guards / Handlebar cover

INDEX

COLOR WIRING DIAGRAMS


Models covered:
2001 2002 2003 2004 2005 2006 2007 2008 HONDA TRX250EX Sportrax
2009 2010 2011 2012 TRX250X

Specifications
Publisher: Clymer Manuals
Softcover: 336 pages
