1971 Ford Mustang, Boss & Cobra Factory Part & Body Illustrations USB
Click to enlarge image(s)

This 1971 Ford Mustang, Boss 429 & Shelby Cobra Factory Part & Body Illustrations on USB is a comprehensive collection of detailed part and body illustrations that are extremely useful for any restoration project. For example, part illustrations are exploded to show not only the parts of a component, but can be used to identify the basic part number of virtually every nut, washer, etc. The exploded body illustrations show the locations of trim pieces, moldings, weather stripping, how sheet metal was assembled, etc. How many washers do you need on the Pitman Arm or what direction is the rear axle yoke bearing? Just look up the illustration and see what it looks like!

MODEL COVERAGE:

  • 1971 Ford Mustang
  • 1971 Ford Shelby Cobra
  • 1971 Ford Boss 429
TABLE OF CONTENTS:
- General Information
- Molding Clip Kits
- Wheels & Brakes
- Front Suspension, Steering, Rear Axle & Drive Shaft
- Frame, Muffler & Springs
- Engine
- Standard Transmission & Clutch
- Automatic Transmission
- Cooling & Grille
- Fuel, Carburetor & Accelerator
- Generator, Alternator, Starter & Distributor
- Lamps & Wiring
- Fender & Hood
- Speedometer, Bumper & Accessories
- Body Parts Index
- Plus Much More!

Features:

  • Printable - Print only the pages you need. Printing must be to a printer physically connected to the computer via a printer port; cannot print to a wireless, network or a virtual printer driver.)
  • Searchable - Search the entire manual in seconds.
  • Indexed - Both alphabetical and numerical (to find illustrations easily)
  • Zoom - Zoom in to over 1200% to see the exact details.
  • Licensed - This product is approved and licensed by Ford Motor Company (License #84356800)
  • Bookmarked - Manual is bookmarked to locate sections in seconds.

System Requirements:

  • Windows, MAC, iOS, or Android
  • USB Drive & PDF Viewer Software is Required
  • Minimum 128MB of RAM
  • Latest Version of Adobe Reader is Recommended
Specifications
Publisher: Forel Publishing Company
Media: USB Drive
