$3,900.00 Reg.
$2,579.00 SALE
|
Item Number
ROB34288
|
|
Quantity:
|
|
We are Authorized Dealers of all Robinair Tools!
(Best Brands Software, LLC, the parent company, is the account holder.)
|
RENEW
|
|
In June 2005, the Society of
Automotive Engineers (SAE) started a research program to
reduce the emissions of R-134a. The program, called I-MAC
(Improved Mobile Air Conditioning), was tasked with cost
effectively improving R-134a systems while
reducing refrigerant emissions.
The I-MAC members have pledged to design smaller systems with
fewer leak points and improve service equipment. As a result
of this program, the SAE recently approved tighter standards
for automotive A/C recovery, recycle and recharge equipment.
The new standard, SAE J-2788, requires that all service
equipment manufactured after December 31,2007, must recover
95% of the refrigerant and recharge to within 1/2 ounce.
For years, R-134a was cheap and
plentiful. Today it’s a different story- refrigerant is much
more expensive and not always available. The Robinair 34288
recovers up to 20% more refrigerant, which means it will cost
less to recharge the system. The best charge accuracy that
could be claimed by older generation service machines was +/-
1 ounce, a 3% error on a two-pound system. That same charge
accuracy on a 14-ounce system is over
twice the error (7%).
Early R-134a systems could still provide some cabin cooling
when they were 4-6 ounces (12-18%) low on refrigerant.
However, new designs are so efficient, they do not have
reserve refrigerant, and charge accuracy is critical. The
Robinair 34288 will recharge the vehicle to within 1/2 ounce
of the charge capacity, and you will avoid
the dreaded “come back”. As the shop owner, you will
realize more profits per service by recovering more
refrigerant and charging less. Refer to the ROI worksheet on
the back of this brochure to determine your actual cost
savings. The savings will be obvious.
|
|
|
|
REFRESH
|
Robinair
Stays Ahead Of The Game With Automated A/C Service
Combines simple operation with superior accuracy. The
Cool-Tech ROB-34288 recovers,
recycles, evacuates, leak tests, and recharges R-134a quickly
and accurately. Semiautomatic operation means less attention
is needed!
|
| Features: |
- Automatic
Recovery - When this mode
is selected, the 34288 looks for pressure
from the vehicle and proceeds if the pressures are
acceptable.
- Automatic
Air Purge - Eliminates
damaging air without any monitoring of gauges
or opening of valves.
- Automatic
Oil Drain - The unit
automatically drains system oil captured during
recovery, and the display reminds you to empty the bottle.
Graduations on the
container clearly show you how much oil needs to be
replaced.
- Refrigerant
Charging - Has never been
this easy. Select a charge mode from
either the low side, or low side and high side. Accuracy
features eliminate
guesswork! (manual operation using panel valves)
- New
Display - The new,
easier-to-read 4 x 20 display features multilingual
capability – The user can select English, Spanish, or
French languages.
- Refrigerant
Management Systems - New
and improved, system displays
refrigerant use and monitors remaining filter life.
Prompts appear when 1/3 of filter
life remains. Replacement Filter Part No. 34724.
- Vacuum
Function - Defaults to 15
minutes, but is programmable up to 99 minutes.
Remaining time is displayed on the screen.
|
|
Specifications
|
|
Voltage
. . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . .
.115V 60 Hz
Refrigerant Container On-board . . . . . . . . .. . 30 lb. (14
kg) vessel (source tank not included)
Operating Range . . . . . . . . . . . . . . . . . . . . . . .
50° to 120°F (11° to 49°C)
Recycling Filter-Drier . . . . . . . . . . . . . . . . . . . .
43 cu. in. spin-on type
Pump Free Air Displacement . . . . . . . . . . .. . 1.5 cfm
(71 L/min)
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . .
. . 50" H x 34" W x 23" D (123 cm x 87 cm x 59
cm)
Shipping Weight . . . . . . . . . . . . . . . . . . . . . . .
. 225 lbs. (102 kg)
|
|
REWARD
|
| Investing
In The Future |
Nat’l Average
|
Your Cost
|
| Return On
Investment |
|
|
A.
Price for A/C Service
B. Value of refrigerant recovered from vehicle being serviced.
Low charge in vehicle (1 lb.) and
recovered at 95% efficiency.
C. Material Cost (1.5 lbs. of R 134a and PAG oil)
D. Labor/Overhead
E. Profit per Service (A+B+C+D)
F. Monthly Profit (25 Services) |
$99.95
$5.70
-$10.00
-$50.00
$45.65
$1,141.25 |
______________
______________
______________
______________
______________
|
Maintain your profitability and avoid costly “come backs”
by ensuring critical charge
accuracy! Refrigerant service equipment manufactured under the
old standard cannot
guarantee charge accuracy. The ROB-34288 can pay for itself in
as little as 3 months. |
|
|
| Combining Simple Operation
With Superior Accuracy: |
Whether it’s the
fully-automatic 34988, 34788 or the semi-automatic 34288, these machines
will test, recover, and recharge R-134a automotive AC systems quickly
and accurately.
|
|
Comparison Chart |
34288 |
34788 |
34988 |
|
Fully-Automatic Function:
Program to recover, vacuum, leak test and charge without
operating panel valves. |
- |
X |
X |
| Automatic Oil measure & Inject: The
machine will automatically determine how much lubrication oil
needs to be injected back into the A/C system based on how much
oil was taken out during recovery. - |
- |
- |
X |
| Automatic Dye Inject: Gives the user the
ability to use the machine to inject UV dye into a vehicle’s A/C
system |
- |
- |
X |
| Automatic Oil Drain: A display reminds
you to empty the graduated container to show the amount of oil
to replace. |
X |
X |
X |
| Oil Inject: Less than 1%
cross-contamination. |
- |
X |
X |
| Refrigerant & Oil Database: For North
American market vehicles 1994 - 2007 (updates available
mid-2008). |
- |
X |
X |
| A/C system flush: Flushes a vehicle’s
A/C system with refrigerant eliminating an residual oil or other
liquid. |
- |
- |
X |
| Save & Print before and after service
data: Allows the user to store before and after service
information by vehicle and print this information to provide to
a customer. |
- |
- |
X |
| Indicator light and notification alarm:
Notifies the user when service is complete, or if a problem has
occurred. |
- |
- |
X |
| Vacuum Leak Test: Monitors level after
evacuation, informs of possible leak. |
- |
X |
X |
| Automatic Air Purge: Eliminates damaging
air without monitoring gauges or opening valves. |
X |
X |
X |
| Automatic Refrigerant Refill: Maintains
a user-selectable amount of refrigerant in an internal vessel
and signals with it’s time to change supply tank, no monitoring
required. |
X |
X |
X |
| Vacuum Feature: Defaults to 15 mins,
programmable up to 99 mins. “Remaining time” is displayed.
|
- |
X |
X |
| Display: Multilingual
|
X |
X |
X |
| Refrigerant Charging: Select a charge
mode from high or low side. |
high or Low |
high/Low/Both |
high/Low/Both |
|
Refrigerant Management
System: Displays refrigerant use and monitors remaining filter
life. Prompts appear when 1/3 of filter life remains.
|
X |
X |
X |
|
