VW 09G / Audi TF60SN Technicians Diagnostic Guide
Click to enlarge image(s)
This manual provides a component application chart, clutch tap identification, exploded views of the valve body, extensive solenoid information, clutch pack configurations, case passage identification, complete hydraulic schematics, bulletins, updates, VAG code and OBD2 code identification.

Contents:
  • Introduction
  • Application Chart
  • Pressure Testing
  • Internal Wiring Harness
  • Wiring Diagram
  • Valve Body
  • Solenoid Information
  • Case Passage Identification
  • Clutch Assemblies
  • Sprag Rotation
  • Fluid Specifications
  • ATSG Bulletins
  • Data Block Information
  • Solenoid Amp Chart
  • Clutch Adapt Re-Set
  • Codes
  • Transmission Digest Articles
Specifications
Publisher: Automatic Transmission Service Group (ATSG)
Looseleaf Binder: Approx. 60 pages
Dimensions: 10.0 x 11.5 x 1.0 inches
