Chrysler Stellantis 948TE 9-Speed ATSG Transmission Rebuild Manual
- Hassle Free Returns - NO RMA's!
- No Restocking Fees
- Over 173,000 Satisfied Customers
- 30 Day Money Back Guarantee*
(*Restrictions Apply. See Return Policy)
|
 |
| Click to enlarge image(s) |
The 948TE (9 forward speeds, 480 N-M, Transverse mounting, Electronic Control), was introduced at the start of production for the 2014 model year and is manufactured at the Kokomo and Tipton Indiana plants under a licensing agreement with ZF. Currently the 948TE is used in the Jeep Cherokee, Renegade and Compass as well as the Chrysler 200 and Pacifica. It is also used in the Ram Promaster (Doblo) and the Fiat 500x and Toro. The ZF9HP48 version which is similar to the 948TE can be found in various Acura and Honda models, Land Rover Evoque and Discovery Sport as well as the Jaguar E-Pace. This manual will show some of the differences between the two versions but will primarily concentrate on the 948TE.
The 948TE transmission can be configured for front wheel drive, all wheel drive or four wheel drive and is found behind the 2.4 liter multi-air L4 or 3.2 liter V6 engines. Although the two versions of this transmission appear very similar, many parts will be different and should be selected carefully. The Transmission Control Module software should always be updated to current versions especially since the early models were inundated with software operational issues.
This ATSG Chrysler / Stellantis 948TE TechTran manual will guide you in the complete teardown and assembly of the 948TE transmission with many diagnostics included as well.
CONTENTS:
- Transmission General Description
- Shift Quadrant Identification
- Transmission Control Module Adaptation Procedure
- Clutch Application / Gear Ratio Chart
- Solenoid Function and Application (Park by Wire)
- Solenoid Function and Application (Park by Cable)
- Solenoid Operation Specifications
- Service Park Release Procedures
- Transmission Case Connector Pin Assignments
- Transmission Control Module Pin Assignments
- Transmission Speed Sensors
- Transmission Fluid Temperature Sensor "A" / Transmission Oil Pressure Sensor
- Transmission Range Sensor
- Diagnostic Trouble Code Definitions
- Transmission Fluid Specifications and Procedures
- 948TE vs ZF8HP48 Transmission Quick Identification
- Transmission Disassemble
- Component Rebuild
- Transmission Assemble
- Transmission Case Passage Identification
- Transmission Final Assemble
- Torque Specifications
- Special Service Tools
| Specifications | |
| Publisher: | ATSG (Automatic Transmission Service Group) |
| Softcover: | 128 Pages |
| Dimensions: | 8.5 x 10.5 x 0.6 inches |
