VOLVO / SAAB 50-42 LE Technicians Diagnostic Guide
Click to enlarge image(s)

This manual covers tear down and assembly, electronic diagnosis, principles of operation, Complete hydraulic circuit diagrams, Valve body spring and valve identification and Valve Body Mapping (passage identification for the valve body and all spacer plates).

Contents:

  • 50-45LE Identification Tag Information
  • Cut-Away View, Clutch and Solenoid Application
  • Gear Ratios and Specifications
  • Component Resistance Charts
  • Transmission Range Switch Check
  • Volvo TCM Wire Schematic
  • Saab TCM Wire Schematic
  • Daewoo TCM Wire Schematic
  • Volvo Trouble Codes and Retrieval
  • Saab Trouble Codes and Retrieval
  • Daewoo Trouble Codes and Retrieval
  • Valve Body Mapping and Passage Identification
  • Valve Body Mapping Circuit Diagram
  • Oil Circuit Diagrams
  • Transmission Disassembly
  • Sub-Assemblies Section
  • Transmission Re-Assembly
  • Case Air Checks
Specifications
Publisher: Automatic Transmission Service Group (ATSG)
Paperback: Approx. 60 pages
Dimensions: 10.0 x 11.5 x 1.0 inches
