2001 Ford Windstar Wiring Diagrams
Click to enlarge image(s)

This manual contains Diagrams with Component Location Illustrations, Circuit Descriptions and Troubleshooting Hints. Information contained has been developed to aid technicians in diagnosing and repairing vehicle wiring and electrical systems. Each manual covers the entire vehicle bumper to bumper including connectors, splices, grounds and component location and testing.

Used factory manual in good condition.

Contents:

  • Grounds
  • Fuse Panel/Circuit Protection
  • Charging System
  • Power Distribution
  • Multiplex Communication
  • Starting System
  • Ignition System
  • Electronic Engine Controls
  • Transmission Controls
  • Speed Control
  • Cooling Fans
  • Shift Lock
  • ABS
  • Horn/Cigar Lighter
  • Air Bag Restraint System
  • Air Conditioner/Heater
  • Rear Window Defrost
  • Multifunction Electronic Control Modules
  • Instrument Cluster
  • Warning Chime
  • Instrument Illumination
  • Interval Wiper/Washer
  • Liftgate Wiper/Washer
  • Headlamps
  • Autolamps
  • Courtesy Lamps
  • Turn/Stop/Hazard Lamps
  • Exterior Lamps
  • Reversing Lamps
  • Trailer Adapter/Electronic Brake
  • Power Windows
  • Overhead Console
  • Compass
  • Power Door Locks
  • Remote Keyless Entry
  • Anti-Theft
  • Power Seats
  • Power Lumbar Seats
  • Power Mirrors
  • Electronic Day/Night Mirror
  • Power Sliding Door
  • Adjustable Pedal
  • Radio
  • Parking Aid
  • Rear Seat Entertainment
  • Component Testing
  • In-Line Connector Faces
  • Component Location Views
  • Location Index
  • Harness Causal Part Number
  • Vehicle Repair Location Codes
Specifications
Publisher: Ford Motor Company
Softcover: Approx. 300 pages
Dimensions: 11.0 x 8.5 x 0.5 inches
